Moody 336
Introduced: December 1988
Ceased: June 1996
Built by: Marine Projects (Plymouth) Limited
Designer: Bill Dixon
Boats Built: 200
Berths:

Forecabin; two single berths, which are convertible to a double. Locker space is provided round the ships sides above the berths. To the port side is a hanging locker and a vanity unit opposite to starboard. Saloon; U shaped settee to port with a single settee to starboard. The centrally mounted saloon table folds out to the complete width of the saloon. The navigation area is situated aft of the saloon to starboard; chart table. The toilet compartment is aft of the navigation area; marina toilet, hot and cold pressurised water, wash basin, shower. The galley situated aft of the saloon on the port side; pressurised hot and cold water, twin sinks, gas cooker, top opening refrigerated ice box. Aft cabin, this extremely large cabin occupies the after end of the boat. Access is from a door aft of the galley. L shaped settee, vanity desk, large double berth.

PRINCIPAL DIMENSIONS
LOA 10.21m 33'6"
LWL 8.76m 28'9"
Beam 3.54m 11'7"
Draft (fin keel) 1.68m 5'6"
Draft (bilge keel) 1.20m 3'11"
Displacement 5720 kg 12584 lbs
Ballast 1809 kg 3990 lbs

TANKAGE
Water 202 ltr 44.5 gal / 53 US gal
Fuel 118 ltr 26 gal / 31 US gal

RIG
I 12.88m 42'3"
J 4.11m 13'6"
P 10.97m 36'
E 3.73m 12'3"

SAIL AREAS
Mainsail 20.44m² 220 sq ft
Working Jib 23.97m² 258 sq ft
No.1 Genoa 36.48m² 425 sq ft
Roller Genoa 35.12m² 378 sq ft

ENGINE
Volvo 2003 28hp, Perkins Perama M30, 29hp diesel engine
